Isis::ImageList Class Reference

#include <ImageList.h>

Inheritance diagram for Isis::ImageList:

Collaboration diagram for Isis::ImageList:

Classes
class	CopyImageDataFunctor
	This functor is used for copying the images between two projects quickly. More...
class	XmlHandler

Signals
void	countChanged (int newCount)

Public Member Functions
	ImageList (QString name, QString path, QObject *parent=NULL)
	Create an image list from an image list name and path (does not read Images).
	ImageList (QObject *parent=NULL)
	Create a blank image list.
	ImageList (QList< Image * >, QObject *parent=NULL)
	Create an image list from a list of images.
	ImageList (Project *project, XmlStackedHandlerReader *xmlReader, QObject *parent=NULL)
	Create an image list from XML.
	ImageList (QStringList &)
	Create an image list from a list of cube file names.
	ImageList (const ImageList &)
	Copy constructor.
	~ImageList ()
	Destructor.
void	append (Image *const &value)
void	append (const QList< Image * > &value)
void	clear ()
iterator	erase (iterator pos)
iterator	erase (iterator begin, iterator end)
void	insert (int i, Image *const &value)
iterator	insert (iterator before, Image *const &value)
void	prepend (Image *const &value)
void	push_back (Image *const &value)
void	push_front (Image *const &value)
int	removeAll (Image *const &value)
void	removeAt (int i)
void	removeFirst ()
void	removeLast ()
bool	removeOne (Image *const &value)
void	swap (QList< Image * > &other)
Image *	takeAt (int i)
Image *	takeFirst ()
Image *	takeLast ()
ImageList &	operator+= (const QList< Image * > &other)
ImageList &	operator+= (Image *const &other)
ImageList &	operator<< (const QList< Image * > &other)
ImageList &	operator<< (Image *const &other)
ImageList &	operator= (const QList< Image * > &rhs)
ImageList &	operator= (const ImageList &rhs)
	Assignment operator.
QList< QAction * >	supportedActions (Project *project=NULL)
	Gets a list of pre-connected actions that have to do with display, such as color, alpha, outline, fill, etc.
bool	allSupport (ImageDisplayProperties::Property prop)
	Returns true if all of the given displays support the property.
void	setName (QString newName)
	Set the human-readable name of this image list.
void	setPath (QString newPath)
	Set the relative path (from the project root) to this image list's folder.
QString	name () const
	Get the human-readable name of this image list.
QString	path () const
	Get the path to these images in the image list (relative to project root).
void	deleteFromDisk (Project *project)
	Delete all of the contained Images from disk (see Image::deleteFromDisk())
void	save (QXmlStreamWriter &stream, const Project *project, FileName newProjectRoot) const
	Convert this image list into XML format for saving/restoring capabilities.

Private Slots
void	askAndUpdateAlpha ()
	Prompt the user for a new alpha value.
void	askAndUpdateColor ()
	Prompt the user for a new color.
void	showRandomColor ()
	This applies a new semi-random color to every image's display property for every image in this image list.
QStringList	saveAndToggleShowDNs ()
	Change the visibility of DNs.
QStringList	saveAndToggleShowFill ()
	Change the visibility of the fill area.
QStringList	saveAndToggleShowLabel ()
	Change the visibility of the display name.
QStringList	saveAndToggleShowOutline ()
	Change the visibility of the outline.

Private Member Functions
QAction *	createWorkOrder (Project *project, ImageListActionWorkOrder::Action action)
void	applyAlphas (QStringList alphaValues)
void	applyColors (QStringList colorValues, int column=0)
void	applyShowLabel (QStringList showLabelValues)
void	applyShowFill (QStringList showFillValues)
void	applyShowDNs (QStringList showDNsValues)
void	applyShowOutline (QStringList showOutlineValues)
bool	askAlpha (int *alphaResult) const
	Prompt the user for a new alpha value.
bool	askNewColor (QColor *colorResult) const
QStringList	saveAndApplyAlpha (int newAlpha)
QStringList	saveAndApplyColor (QColor newColor)
QStringList	saveAndApplyRandomColor ()

Private Attributes
QString	m_name
QString	m_path
	This stores the directory name that contains the images in this image list.

Friends
class	ImageListActionWorkOrder

Detailed Description

Author

2012-??-?? ???

History:

2014-01-08 Tracie Sucharski - Added layer re-ordering connections to all images in list instead of just the first image. Fixes #1755.

Definition at line 29 of file ImageList.h.

Constructor & Destructor Documentation

Isis::ImageList::ImageList	(	QString	name,
		QString	path,
		QObject *	parent = NULL
	)

Create an image list from an image list name and path (does not read Images).

Parameters

name	The ImageList's name (i.e. import1, import2, ...)
path	The ImageList's folder name (i.e. import1, import2, ...)
parent	The Qt-relationship parent

Definition at line 52 of file ImageList.cpp.

References m_path, name(), and path().

Isis::ImageList::ImageList ( QObject *  parent = NULL )

explicit

Create a blank image list.

Parameters

parent

The Qt-relationship parent

Definition at line 63 of file ImageList.cpp.

Isis::ImageList::ImageList ( QList< Image * >  images, QObject *  parent = NULL  )

explicit

Create an image list from a list of images.

Parameters

images	The list of images
parent	The Qt-relationship parent

Definition at line 73 of file ImageList.cpp.

References append().

Isis::ImageList::ImageList ( Project *  project, XmlStackedHandlerReader *  xmlReader, QObject *  parent = NULL  )

explicit

Create an image list from XML.

Parameters

project	The project with the image list
xmlReader	The XML reader currently at an <imageList> tag.
parent	The Qt-relationship parent

Definition at line 85 of file ImageList.cpp.

Isis::ImageList::ImageList ( QStringList &  fileNames )

explicit

Create an image list from a list of cube file names.

This is slow (serial) and not recommended.

Definition at line 106 of file ImageList.cpp.

References append().

Isis::ImageList::ImageList

(

const ImageList &

other

)

Copy constructor.

Parameters

other

The ImageList to copy

Definition at line 96 of file ImageList.cpp.

References m_path.

Isis::ImageList::~ImageList

(

)

Destructor.

This does not free the Images from memory.

Definition at line 121 of file ImageList.cpp.

Member Function Documentation

bool Isis::ImageList::allSupport

(

ImageDisplayProperties::Property

prop

)

Returns true if all of the given displays support the property.

Parameters

prop	The property we're testing for support for
displays	The displays we're doing the test on

Definition at line 527 of file ImageList.cpp.

References Isis::Image::displayProperties(), and Isis::DisplayProperties::supports().

Referenced by supportedActions().

void Isis::ImageList::append

(

Image *const &

value

)

See Also

QList<Image *>::append()

Definition at line 128 of file ImageList.cpp.

Referenced by Isis::MosaicSceneItem::contextMenuEvent(), Isis::MosaicSceneWidget::contextMenuEvent(), Isis::MosaicSceneWidget::getSelectedCubes(), ImageList(), Isis::Footprint2DViewWorkOrder::syncRedo(), and Isis::MosaicSceneWidgetTester::testBasicFunctionality().

void Isis::ImageList::append

(

const QList< Image * > &

value

)

See Also

QList<Image *>::append()

Definition at line 137 of file ImageList.cpp.

bool Isis::ImageList::askAlpha ( int *  alphaResult ) const

private

Prompt the user for a new alpha value.

If the user selects a new alpha then this sets alphaResult and returns true.

Definition at line 785 of file ImageList.cpp.

References Isis::ImageDisplayProperties::Color, and Isis::DisplayProperties::getValue().

Referenced by askAndUpdateAlpha(), and Isis::ImageListActionWorkOrder::execute().

void Isis::ImageList::askAndUpdateAlpha ( )

privateslot

Prompt the user for a new alpha value.

If the user selects a new alpha then every image's display properties is updated.

Definition at line 884 of file ImageList.cpp.

References askAlpha().

Referenced by supportedActions().

void Isis::ImageList::askAndUpdateColor ( )

privateslot

Prompt the user for a new color.

If the user selects a new color then every image's display properties is updated.

Definition at line 898 of file ImageList.cpp.

Referenced by supportedActions().

void Isis::ImageList::clear

(

)

See Also

QList<Image *>::clear()

Definition at line 146 of file ImageList.cpp.

void Isis::ImageList::deleteFromDisk

(

Project *

project

)

Delete all of the contained Images from disk (see Image::deleteFromDisk())

Definition at line 586 of file ImageList.cpp.

References Isis::Image::deleteFromDisk(), Isis::Project::imageDataRoot(), and m_path.

Referenced by Isis::Project::deleteAllProjectFiles().

QList< Image * >::iterator Isis::ImageList::erase

(

iterator

pos

)

See Also

QList<Image *>::erase()

Definition at line 158 of file ImageList.cpp.

Referenced by Isis::MosaicController::imageClosed().

QList< Image * >::iterator Isis::ImageList::erase	(	iterator	begin,
		iterator	end
	)

See Also

QList<Image *>::erase()

Definition at line 168 of file ImageList.cpp.

void Isis::ImageList::insert	(	int	i,
		Image *const &	value
	)

See Also

QList<Image *>::insert()

Definition at line 178 of file ImageList.cpp.

QList< Image * >::iterator Isis::ImageList::insert	(	iterator	before,
		Image *const &	value
	)

See Also

QList<Image *>::insert()

Definition at line 188 of file ImageList.cpp.

QString Isis::ImageList::name

(

)

const

Get the human-readable name of this image list.

Returns

The name of the image list (or an empty string if anonymous).

Definition at line 567 of file ImageList.cpp.

Referenced by Isis::ExportImagesWorkOrder::execute(), Isis::CubeViewportViewWorkOrder::execute(), Isis::Footprint2DViewWorkOrder::execute(), Isis::ImageFileListViewWorkOrder::execute(), Isis::ImageGroupTreeWidgetItem::ImageGroupTreeWidgetItem(), ImageList(), and Isis::ImageList::XmlHandler::startElement().

ImageList & Isis::ImageList::operator+=

(

const QList< Image * > &

other

)

See Also

QList<Image *>::operator+=()

Definition at line 322 of file ImageList.cpp.

ImageList & Isis::ImageList::operator+=

(

Image *const &

other

)

See Also

QList<Image *>::operator+=()

Definition at line 336 of file ImageList.cpp.

ImageList & Isis::ImageList::operator<<

(

const QList< Image * > &

other

)

See Also

QList<Image *>::operator<<()

Definition at line 346 of file ImageList.cpp.

References operator<<().

ImageList & Isis::ImageList::operator<<

(

Image *const &

other

)

See Also

QList<Image *>::operator<<()

Definition at line 360 of file ImageList.cpp.

References operator<<().

ImageList & Isis::ImageList::operator=

(

const QList< Image * > &

rhs

)

See Also

QList<Image *>::operator=()

Definition at line 370 of file ImageList.cpp.

ImageList & Isis::ImageList::operator=

(

const ImageList &

rhs

)

Assignment operator.

Parameters

rhs	The right hand side of the '=' operator

Returns

*this

Definition at line 388 of file ImageList.cpp.

References m_path.

QString Isis::ImageList::path

(

)

const

Get the path to these images in the image list (relative to project root).

This only applies to an image list from the project.

Returns

The path to the images in the image list (or an empty string if unknown).

Definition at line 578 of file ImageList.cpp.

References m_path.

Referenced by ImageList(), and Isis::ImageList::XmlHandler::startElement().

void Isis::ImageList::prepend

(

Image *const &

value

)

See Also

QList<Image *>::prepend()

Definition at line 198 of file ImageList.cpp.

void Isis::ImageList::push_back

(

Image *const &

value

)

See Also

QList<Image *>::push_back()

Definition at line 207 of file ImageList.cpp.

void Isis::ImageList::push_front

(

Image *const &

value

)

See Also

QList<Image *>::push_front()

Definition at line 216 of file ImageList.cpp.

int Isis::ImageList::removeAll

(

Image *const &

value

)

See Also

QList<Image *>::removeAll()

Definition at line 225 of file ImageList.cpp.

void Isis::ImageList::removeAt

(

int

i

)

See Also

QList<Image *>::removeAt()

Definition at line 239 of file ImageList.cpp.

Referenced by Isis::Project::imageClosed().

void Isis::ImageList::removeFirst

(

)

See Also

QList<Image *>::removeFirst()

Definition at line 248 of file ImageList.cpp.

void Isis::ImageList::removeLast

(

)

See Also

QList<Image *>::removeLast()

Definition at line 257 of file ImageList.cpp.

bool Isis::ImageList::removeOne

(

Image *const &

value

)

See Also

QList<Image *>::removeOne()

Definition at line 266 of file ImageList.cpp.

void Isis::ImageList::save	(	QXmlStreamWriter &	stream,
		const Project *	project,
		FileName	newProjectRoot
	)		const

Convert this image list into XML format for saving/restoring capabilities.

This writes:

  <imageList name="..." path="...">

to the given xml stream, and creates an 'images.xml' inside the folder with the images. Inside the images.xml, this writes:

  <images>
    ...
  </images>

Definition at line 616 of file ImageList.cpp.

References _FILEINFO_, Isis::Project::imageDataRoot(), Isis::IException::Io, m_path, Isis::FileName::path(), and Isis::Image::save().

QStringList Isis::ImageList::saveAndToggleShowDNs ( )

privateslot

Change the visibility of DNs.

This synchronizes all of the values where at least one is guaranteed to be toggled.

Definition at line 921 of file ImageList.cpp.

References Isis::Image::displayProperties(), Isis::DisplayProperties::getValue(), Isis::ImageDisplayProperties::setShowDNs(), and Isis::ImageDisplayProperties::ShowDNs.

Referenced by supportedActions().

QStringList Isis::ImageList::saveAndToggleShowFill ( )

privateslot

Change the visibility of the fill area.

This synchronizes all of the values where at least one is guaranteed to be toggled.

Definition at line 946 of file ImageList.cpp.

References Isis::Image::displayProperties(), Isis::DisplayProperties::getValue(), Isis::ImageDisplayProperties::setShowFill(), and Isis::ImageDisplayProperties::ShowFill.

Referenced by supportedActions().

QStringList Isis::ImageList::saveAndToggleShowLabel ( )

privateslot

Change the visibility of the display name.

This synchronizes all of the values where at least one is guaranteed to be toggled.

Definition at line 971 of file ImageList.cpp.

References Isis::Image::displayProperties(), Isis::DisplayProperties::getValue(), Isis::ImageDisplayProperties::setShowLabel(), and Isis::ImageDisplayProperties::ShowLabel.

Referenced by supportedActions().

QStringList Isis::ImageList::saveAndToggleShowOutline ( )

privateslot

Change the visibility of the outline.

This synchronizes all of the values where at least one is guaranteed to be toggled.

Definition at line 996 of file ImageList.cpp.

References Isis::Image::displayProperties(), Isis::DisplayProperties::getValue(), Isis::ImageDisplayProperties::setShowOutline(), and Isis::ImageDisplayProperties::ShowOutline.

Referenced by supportedActions().

void Isis::ImageList::setName

(

QString

newName

)

Set the human-readable name of this image list.

This is really only useful for project image lists (not anonymous temporary ones).

Parameters

newName

The name to give this image list

Definition at line 546 of file ImageList.cpp.

void Isis::ImageList::setPath

(

QString

newPath

)

Set the relative path (from the project root) to this image list's folder.

This is really only useful for project image lists (not anonymous temporary ones).

Parameters

newPath

The path to the images in this image list

Definition at line 557 of file ImageList.cpp.

References m_path.

void Isis::ImageList::showRandomColor ( )

privateslot

This applies a new semi-random color to every image's display property for every image in this image list.

Definition at line 909 of file ImageList.cpp.

References Isis::Image::displayProperties(), Isis::ImageDisplayProperties::randomColor(), and Isis::ImageDisplayProperties::setColor().

Referenced by supportedActions().

QList< QAction * > Isis::ImageList::supportedActions

(

Project *

project = NULL

)

Gets a list of pre-connected actions that have to do with display, such as color, alpha, outline, fill, etc.

Definition at line 407 of file ImageList.cpp.

References allSupport(), askAndUpdateAlpha(), askAndUpdateColor(), Isis::ImageDisplayProperties::Color, Isis::Image::displayProperties(), saveAndToggleShowDNs(), saveAndToggleShowFill(), saveAndToggleShowLabel(), saveAndToggleShowOutline(), Isis::ImageDisplayProperties::ShowDNs, Isis::ImageDisplayProperties::ShowFill, Isis::ImageDisplayProperties::ShowLabel, Isis::ImageDisplayProperties::ShowOutline, showRandomColor(), Isis::ImageDisplayProperties::Zooming, and Isis::ImageDisplayProperties::ZOrdering.

Referenced by Isis::MosaicSceneItem::contextMenuEvent(), and Isis::MosaicSceneWidget::contextMenuEvent().

void Isis::ImageList::swap

(

QList< Image * > &

other

)

See Also

QList<Image *>::swap()

Definition at line 280 of file ImageList.cpp.

Image * Isis::ImageList::takeAt

(

int

i

)

See Also

QList<Image *>::takeAt()

Definition at line 292 of file ImageList.cpp.

Image * Isis::ImageList::takeFirst

(

)

See Also

QList<Image *>::takeFirst()

Definition at line 302 of file ImageList.cpp.

Image * Isis::ImageList::takeLast

(

)

See Also

QList<Image *>::takeLast()

Definition at line 312 of file ImageList.cpp.

Member Data Documentation

QString Isis::ImageList::m_path

private

This stores the directory name that contains the images in this image list.

For example: import1 or import2

This path is relative to Project::imageDataRoot()

Definition at line 196 of file ImageList.h.

Referenced by deleteFromDisk(), ImageList(), operator=(), path(), save(), and setPath().

---

The documentation for this class was generated from the following files:

• src/qisis/objs/ImageList/ImageList.h
• src/qisis/objs/ImageList/ImageList.cpp
